Aircraft Stand Manoeuvring Guidance Light (LED)

Features

• The LED light is featured by long working life, energy conversation, maintenance-free, which brings enormous economic benefits to customers
• Specially-designed LED lens to greatly improve luminous efficacy of LED lights
• Proprietary prism structural design and manufacturing process to ensure excellent optical performance
• Strict LED color management to ensure premium color consistency
• Light distribution consistent with that of halogen lights, complying with FAA standards
• Proprietary driver circuit and thermal management solution, which greatly improves the reliability and service life of light fixture
• Power factor above 0.9, which minimizes the power network disturbance
• Optional function of single lamp failure detection, which enables the light to simulate open circuit of halogen lamp when the LED light is damaged
• Specially-designed structure, protruding only 6.35mm above finish grade
• Upper cover with flat out-light surface to prevent from water buildup and ensure high luminous efficiency
• Upper cover with equal-strength design and forging craft, which has premium mechanical and barrier capacity, and shock resistance ability
• Smooth and sleek upper cover to prevent from damaging aircraft tires
• Lighting fixture made of highly conductive aluminum alloy, which ensures good heat dispersion
• Main structure made of corrosion-resistant aluminum alloy with special anodic oxidation treatment, all fasteners are made of stainless steel, suitable for harsh environment application
• High-precision parts and components machining to ensure all dimensional quality and precision
• IP68-grade, that can withstand inner pressure of up to 138kpa or water pressure generated from aircrafts' impact on the optical window
• Interchangeable, modular-designed components, applicable for all kinds of 8-inch omni-directional in-pavement taxiway lights(LED type)

Brochure
